Thetford PCB Control Board for C223 Cassette Toilet

This is the internal printed circuit board fitted behind the control panel on Thetford's C220 Series cassette toilets, managing the electric flush button, pump operation and panel indicators. If the toilet stops flushing, the flush button stops responding, or the control panel behaves erratically despite a healthy 12V supply and clean wiring, a failed PCB is a common cause, and this board (Thetford part 200962) is the genuine replacement. It connects using the original wiring plugs, so no rewiring or soldering is needed to fit it.

• Component: Cassette toilet control PCB
• Manufacturer part number: 200962
• Suits: Thetford C222 SWE, C223S and C223CS cassette toilets
• Barcode: 8710315023244
• Approx. shipping size: 160 x 70 x 40mm

• Q: How do I know if my toilet's PCB has failed, or if it's just the battery?
  A: First check the caravan's 12V supply and toilet fuse; if voltage is present at the toilet but the flush button, pump or indicator lights still don't respond, the PCB is the most likely fault.
• Q: Will this board fit my C220 or C260 toilet?
  A: This board (200962) is specifically for the C222 SWE, C223S and C223CS models, other C-series toilets use different control boards, so check your toilet's model plate before ordering.
• Q: Do I need to remove the whole toilet to fit it?
  A: No, the PCB sits behind the control panel and is accessed by removing the panel cover, without needing to unbolt the toilet from the floor.
• Q: Does it come with any wiring or connectors?
  A: It's supplied as the board only, using the same plug connectors as the original, so your existing harness simply reconnects to the new board.
